In Pursuit of High Image Quality and Ease of Use for everyone

"CJV200 Series" is a print & cut eco-solvent inkjet printer which equipped with a single print head of "330 Engine" in our flag-ship printer, enabling even inexperienced operators to produce printed products beautifully, quickly, and easily.



Total sign printing package

High value in a small footprint, the CJV200 provides indoor and outdoor durable printing with an integrated cutter and easy-to-use software for the perfect stand-alone bundle. *One year Mimaki Total Care warranty, two years Mimaki Parts Plus+ warranty
  • Easily produce indoor and outdoor prints on a large selection of media with ‘one printer to do it all’ versatility in a small footprint.
  • Enjoy outstanding quality and productivity, plus the industry’s best outdoor durability at an attractive price point.
  • Print a wide range of applications using this complete system with print & cut device, software, and a range of inks.
  • Easy to use with paired RIP software for extreme accuracy when creating instant decals and large wall graphics.
  • Outstanding quality and productivity at an attractive price point.
  • Mimaki Core Technologies deliver exceptional results, economically, and with maximum productivity.
  • Select from three model widths to suit your production needs



Product outlines

  • Beautiful printing. Mimaki's flag-ship printer's "330 Engine" a single print head is mounted to achieve high image quality.
  • Reliable even during busy periods. Highest practical print speed at entry level: 17.0 m²/h
  • Simple design that is easy for anyone to use. Easy to work with, easy to check, and easy to maintain.
  • New SS22 ink, which does not contain GBL, a controlled substance, is provided in an environmentally friendly paper cartridge.



Line-up

CJV200-75



CJV200-75

Suitable for simple stickers and labels
・Max. Print / Cut Width:800 (31.5") mm
・Max. Media Width:810 (31.9") mm











CJV200-130


CJV200-130

Suitable for variously sized signage and
point-of-sale marketing materials

・Max. Print / Cut Width:1,361 (53.6") mm
・Max. Media Width:1,371 (54.0") mm












CJV200-160

CJV200-160

Suitable for cost effective production of large,
high-quality signage and vehicle wrapping films

・Max. Print / Cut Width:1,610 (63.4") mm
・Max. Media Width:1,620 (63.8") mm

















shop.hsi.usprism white









Specifications

Printhead

One on-demand piezo print head (single)

Print resolution

X: 600,1200 dpi | Y: 600,900,1200 dpi

Print speed (4 color mode)

183 sqft/hr (17 sqm/hr)

Maximum Print Area

CJV200-75: 31.5 in (800 mm)

CJV200-130: 53.6 in (1361 mm)

CJV200-160: 63.4 in (1610 mm)

Maximum media width

CJV200-75: 31.9 in (810 mm)

CJV200-130: 53.9 in (1371 mm)

CJV200-160: 63.8 in (1620 mm)

Maximum Media Thickness

up to 0.04 in (1 mm)

Maximum Media Weight

55 lbs. (25 kg)

Ink Type

Eco-Solvent inks: SS22 (C, M, Y, K, Lc, Lm, Lk, Or)

Interface

USB 2.0 Hi-speed | Ethernet 1000 BASE-T

Power Supply

AC (100-120V / 200-240V±10%) × two 50/60Hz±1Hz

Power Consumption

Max. 1320W x2 | Sleep mode: 4.5W

Operational Environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

CJV200-75: 77 in W x 29.5 in D x 54 in H (1960 mm W × 748 mm D × 1370 mm H)

CJV200-130: 99 in W x 29.5 in D x 54 in H (2520 mm W ×748 mm D×1370 mm H)

CJV200-160: 109 in W x 29.5 in D x 54 in H (2770 mm W x 748 mm D x 1370 mm H)

Weight

CJV200-75: 231.4 lbs. (105 kg)

CJV200-130: 286.6 lbs. (130 kg)

CJV200-160: 308.6 lbs. (140 kg)

Certifications

VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage,

Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, EAC, KC, UKCA

Inks

Eco-Solvent ink (SS22) Cyan Magenta Yellow Black Light Cyan Light Magenta Light Black Orange
440ml cartridge SS22-C-44 SS22-M-44 SS22-Y-44 SS22-K-44 SS22-LC-44 SS22-LM-44 SS22-LK-44 SS22-OR-44
1L Bulk Ink Pack* SPC-0588C SPC-0588M SPC-0588Y SPC-0588K SPC-0588LC SPC-0588LM SPC-0588LK SPC-0588OR
