UCJV 330 UV LED Printer
Leading The Way For UV-LED Technology
- Significantly improved image quality and productivity. Mimaki’s UV printing technology achieved high image quality even at high speeds.
- Clear ink that expands the design potential makes it possible to produce high value-added printed deliverables. Furthermore, 2.5D print and watermark print functions have been added.
- Support for up to 5-layer printing and it expands the range of applications and the added value of deliverables.
- Equipped UV curable ink that does not require drying time after printing and a post-print cut function. Can be used for a wide variety of applications such as store decorations, posters, labels, stickers, pop-ups, etc.
- PICT supports customers in improving the efficiency of their printing operations and production management by enabling them to visualize the operational status and performance of their printers from a PC or mobile device, even from a remote location.
UCJV330 Specifications
Print head |
Two in-line on-demand piezo heads |
Print Resolutions |
600 dpi, 1200 dpi, 1800 dpi |
Maximum Print Area |
UCJV330-130: 53.5″ (1360 mm) |
Maximum media width |
UCJV330-130: 53.9″ (1370 mm) |
Maximum Media Thickness |
up to 1 mm |
Maximum Media Weight |
99.2 lbs. (45.0 kg) |
Ink Type |
U.S. & Canada- LUS-170, LUS-200 |
Interface |
Ethernet 1000 BASE-T (recommended), USB2.0 Hi-Speed |
Power Supply |
Single phase AC100-120V±10% /12A or |
Power Consumption |
Max. 1,440W or less x1 / 800W (Continuous operation) / 4.5W or less (Sleep mode) |
Operational Environment |
Temperature 68° – 86° F (20-30° C) |
Dimensions (W × D × H) |
UCJV330-130: 103.9 x 31.5 x 58.3″ (2,640 x 800 x 1,480mm) |
Weight |
UCJV330-130: 478.4 lbs. (217 kg) |
Safety Standard |
IEC 62368-1 Standard ETL |
![]() |
![]() |
![]() |
![]() |
Outdoor signboard | Illumination signboard | Window graphics | Floor sign |
![]() |
![]() |
![]() |
![]() |
Banners and flags (fabric) | Swing P.O.P. (PET film) | Label | Wallpaper |
